ELECTRICAL MEASUREMENT LABORATORY (Z0612)

Electrical Measurement Laboratory is designed to carry out basic electrical measurements practical for the students in all disciplines. Specially this lab is used by semester I and Semester II students. It houses a variety of test equipment including Digital oscilloscopes, signal generators, analog/digital multimeters, LUX meter, LCR meter, Soldering iron, Digital thermometer, Rheostats, Electrical Wiring Installation board, power supplies ext.

RESOURCES

Yakogawa - Precision Double Bridge	Electronic Galvanometer Measuring Range: 0.10000 mΩ to 111.10 Ω in five digits
Power Distribution Panel
Single Phase Wattmeter	Current Range 5-25 A, Voltage Range 120-240 V AC frequencies 45-65 Hz Principle: Electrodynamometer Type
Tektronix - Digital Oscilloscope	200MHz, 150 MHz, 100 MHz, 70 MHz, 50 MHz, and 30 MHz 1 bandwidth models 2-channel models, Up to 2 GS/s sample rate on all channels Advanced triggers including pulse & line-selectable video triggers
Tektronix – Function Generator	2 Channel, 25 MHz Sine Function Generator, 12.5 MHz Pulse Generator, 14-bit Arbitrary Waveform Generator, 200 MHz Frequency Counter 125 MS/s Sampling Rate & Color TFT LCD

In-charge of Laboratory

	Mrs. BAS Priyanka Lecturer-in-charge
	Mr. BCK Karunarathna Technical Officer
	Mrs. HHMTHMKW Menike Lab Attendant
