OPTOELECTRONICS LABORATORY (U1616)

Optoelectronics Laboratory is designed to give students a basic and advanced understanding of electronic circuits. It houses a variety of test equipment including Digital Oscilloscopes, Function Generator, Spectrum Analyzer and Trainer Panels.

RESOURCES
  1. Tektronix TBS1102B – Digital Oscilloscope
    • 200MHz, 150 MHz, 100 MHz, 70 MHz, 50 MHz, and 30 MHz 1 bandwidth models
    • 2-channel models
    • Up to 2 GS/s sample rate on all channels
    • 2.5k point record length on all channels
    • Advanced triggers including pulse and line-selectable video triggers
  2. Tektronix AFG1022 – Function Generator
    • 25 MHz Sine Function Generator
    • 12.5 MHz Pulse Generator
    • 2 to 8, 192 points, 14-bit Arbitrary Waveform Generator
    • 200 MHz Frequency Counter
    • 2 Channel
    • 125 MS/s Sampling Rate
    • Color TFT LCD
  3. DC Dual Variable Power Supplier
  4. Keysight N9320B – Spectrum Analyzer (9 kHz to 3 GHz)
  5.  AimTTI – Pulse Generator
  6. DeLorenzo – Basic Opto Electronic System Trainer
  7. DeLorenzo – Trainer Panel for Linear Regulators
  8. DeLorenzo – Trainer Panel for Switch Mode Regulators

In-charge of Laboratory
Eng. (Mrs.) AWCK Atugoda

Eng. (Mrs.) AWCK Atugoda
Lecturer-in-charge

Mr. DMBP Dhanapala

Mr. DMBP Dhanapala
Technical Officer

Mr. KARK  Priyadarshana

Mr. KARK Priyadarshana
Lab Attendant
